RSM-500 RSM-600 RSM-1000 RSM-1500 RSM-2000 RSM-3000
Availability: | |
---|---|
Quantity: | |
General Introduction:
Ningbo RHONG Machinery R brand RSM Series big size large capacity screw type spiral vertical plastic color mixer machine is widely used for mixing of various plastic pellets and granules material and masterbatch. RHONG RSM Series big plastic mixer can be also equipped with heating and drying system as option. The machine can mix and dry material at same time, so plastic mixing and drying is very even and exhaustive. RSM Series plastic mixer machine are widely used in plastic injection molding industries, plastic extrusion line factory and blowing molding factories.
Main Features:
1.Overload protection system to protect mixing motor.
2.Optional dry system can dry material completely and better than normal hopper dryer.
3.Microcomputer system to control the mixing time automatically.
4. Machine equipped with outlet port to connect with vacuum autoloader for fast transportation of material..
5. High efficiency mixing motor for energy-saving.
Specification:
Name | Screw Type Hopper Mixer Machine | ||||||
Model | RSM-500 | RSM-600 | RSM-1000 | RSM-1500 | RSM-2000 | RSM-3000 | |
Power | Kw | 2.2 | 2.2 | 4 | 5.5 | 5.5 | 7.5 |
Rotor Speed | RPM | 420 | 420 | 420 | 390 | 390 | 390 |
Mixing capacity | Kg/ min | 500/15 | 600/15 | 1000/15 | 1500/20 | 2000/20 | 3000/30 |
Weight | Kg | 360 | 400 | 550 | 650 | 750 | 900 |
L | mm | 1430 | 1430 | 1500 | 1700 | 1820 | 2000 |
W | mm | 1240 | 1240 | 1400 | 1800 | 2050 | 2300 |
H | mm | 2570 | 2670 | 3020 | 3410 | 3520 | 3950 |
Please excuse for not note if some specifications of products are changed!
Note:
1)The standard power supply is 3Ø 380V 50Hz. Other power supply is available.
2)N
