RCD-9 RCD-20
Availability: | |
---|---|
Quantity: | |
General Introduction:
Ningbo Beilun RHONG Machinery Manufacturing Co., Ltd. RCD Series plastic cabinet dryers can used to dry all type plastic materials. RHONG brand RCD Series plastic chamber dryers can dry different plastic material at the same time. Except plastic processing and molding industries, RCD Series cabinet dryer can be also used electronic, painting, printing, electroplating industries and so on.
Main Features:
1. The baking trays are made of stainless steel to keep material out of pollution.
2. Digital P.I.D. temperature controller to control temperature in a high precision..
3. Air inlet and outlet can be adjusted to control the air flow.
4. Overload device to protect motor.
5. With 24 hours timer to open and stop machine automatically.
Specification:
Name | Cabinet Dryer / Oven Dryer | ||
Model | RCD-9 | RCD-20 | |
Heater Power | KW | 4.5 | 9 |
Fan Power | KW | 0.37 | 1.5 |
Max. Temperature | ℃ | 250 | 250 |
Tray Qty. | Pcs | 9 | 20 |
Capacity | Kg | 100 | 200 |
Internal Size | mm | 880x580x500 | 1000x970x800 |
External Size | mm | 1500x780x650 | 1750x1210x950 |
Weight | kg | 170 | 380 |
Please excuse for not note if some specifications of products are changed.
Note:
The standard power supply is 3Ø 380V 50Hz. Other power supply is available.
